Description
Description:
The machine is a high-quality and high-performance filling and sealing packaging machine for liquid and paste containers. Tube filling and sealing machine adopts manual tube feeding, automatic color code detection, automatic filling, automatic tube tail sealing and automatic tail cutting. Simple, stable and reliable to help enterprises improve production efficiency and reduce labor intensity.
Application:
This machine is suitable for various plastic hoses and aluminum-plastic pipes such as toothpaste, cosmetics, food, industrial supplies, etc
Parameter:
|
Model |
LT-002 |
|
Voltage |
220/110V |
|
Power |
2KW |
|
Frequency |
20kHZ |
|
Workstation |
single station |
|
Filling range |
6-60ml/10-120ml/25-250ml/50-500ml |
|
Filling accuracy |
±1% |
|
Sealing speed |
10-12pcs/min |
|
Tube height |
50-220mm |
|
Tube diameter |
10-50mm |
|
Applicable tube material |
Plastic composite tube, aluminum-plastic tube |
|
Air pressure |
0.5-0.6MPa |
|
Air consumption |
0.2m³/min |
|
Size |
860*650*1550mm |
|
Weight |
130kg |
