Description
Description
1. The level control liquid filling machine is negative pressure type semi-automatic filling machine, mainly used in cologne, perfume, lubricating oil, detergent, such as liquid filling material.
2. There are two kinds of models, double head and four heads type.
3. It has a definite way of liquid level measurement performance; liquid level height can be adjusted.
4. The machine structure is compact and reasonable, simple operation, easy maintenance, and material contact parts made of 304 stainless steels.
5. It is suitable for filling glass bottles and plastic bottles which are not easy to deform after vacuum.
Application:
The four-head vacuum liquid filling machine is a purely pneumatic machine that requires no electricity. It is one of our most economical filling machines, especially suitable for filling small doses of aqueous products such as perfume and flower lotion.
|
Model |
LT-G4000 |
|
The height of bottle |
≤250mm |
|
Max diameter of the bottle |
≤Φ35mm |
|
Min diameter of the bottle |
≤Φ4.5mm |
|
Adjustable liquid level height (from the bottle) |
15-50mm |
|
Liquid level accuracy |
±1mm |
|
Capacity |
40 pcs/min |
|
Dimension (not including the liquid storage pot) (L*W*H) |
660*470*1330mm |
|
Working temperature |
0-30℃ |
|
Power |
0.75kw |
|
Air pressure |
0.5-0.8MPa |
|
Pumping speed |
5.5L/S |
