Description
Description
This semi-automatic pneumatic filling machine is mainly suitable for high viscosity paste containing particles and prone to oil-water stratification.Adopts high end gas-pressure meter,operation is more accurate,the filling volume or filling speed can be adjusted according to your needs.Each nozzle of this machine can be controlled separately.This one is with bottle holder,more reasonable design.
Application：
Widely used in various products,such as sweet and spicy sauce, chili sauce, beef sauce, bean paste, hot pot bottom material,edible oil, mineral water, fruit juice, shampoo, detergent, etc
Technical Parameters
|
Model |
LT-LGF100 |
|
Voltage |
220V/50Hz 110V/60Hz |
|
Power |
100W |
|
Energy Source |
Electric and pneumatic |
|
Filling Nozzle |
1 or 2 Nozzles |
|
Filling Range |
5-100ml/30-300ml/50-500ml/100-1000ml/500-3000ml/1000-5000ml |
|
Filling Speed |
About 12-20 bottles/min |
|
Filling Accuracy |
±1% |
|
Air Pressure |
0.4-0.6MPa |
|
Height of Bottle Holder |
Adjustable |
|
Package Weight |
72.5kgs |
|
Package Size |
1310*575*930mm |
