Description
Description：
The desktop four head pneumatic piston paste filling machine is a continuous automatic quantitative filling equipment that adopts the piston volumetric metering principle and is compatible with liquids, semi fluids, and paste sauces. Desktop structure, small footprint, suitable for small and medium-sized production workshops
Application：
Suitable for automatic quantitative filling of liquids, semi-liquids and pastes.Widely used in food,daily chemical and chemical industries for honey,sauce,edible oil, laundry liquid,cream,detergent and more.
|
Machine model |
LT-DPFG4 |
|
Voltage |
220/110V |
|
Power |
300W |
|
Filling speed |
About 20-30pcs/min |
|
Air pressure |
0.4-0.8Mpa |
|
Filling range |
10-100ml/30-300ml/50-500ml/100-1000ml/500-3000ml/1000-5000ml |
|
Filling accuracy |
≤±1% |
|
Hopper size |
About 90L |
|
Size |
About 1550*1400*1330mm |
|
Weight |
About 240kg |
