Description
Description：
This machine adopts the touch screen operation, PLC control, drive stepper motor to control the bag length,stable performance,easy to adjust and accurate detection.Choose the intelligent temperature controller and PID control to ensure the error range of temperature controlled within 1 degree Centigrade.
Application:
The machine is suitable for vacuum metering packaging of granular items in the food,chemical, and cosmetics industries,such as nuts, peanuts, seeds, grains, chinese wolfberry,and rice,etc.
Technical parameters：
|
Model |
LT-YS61XBK(vacuum) |
|
Voltage |
220V |
|
Power |
1.4KW |
|
Packing type |
Back side sealing |
|
Packing speed |
15-25bags/min |
|
Bag length |
30-170mm |
|
Bag width |
30-130mm(Need to replace the bag former |
|
Filling range |
1-100g |
|
Machine weight |
260kg |
|
Machine size |
730 * 1000* 1780mm |
